Thrust Ball Bearings

Single direction thrust ball bearings with flat back face Double direction thrust ball bearings with flat back face Angular contact trust ball bearings

Thrust Ball Bearings

Single direction thrust ball bearings with flat back face

Single-direction thrust ball bearings are designed exclusively to handle axial loads in one direction. These bearings include a flat housing washer and an aligning seat washer. Typically, the flat housing washer does not allow for angular misalignment. However, during installation, a gap of 0.5-1 mm can be left between the outer diameter of the housing washer and the mounting surface to compensate for minor angular errors.

Note:
  • Aligning seat washers must be ordered separately if required for specific applications.
Common Uses:
  • Used in compressors, centrifugal pumps, and other equipment where axial load handling in one direction is needed.
Designation Principal dimensions Basic load ratings Limiting speed
Dynamic Static Grease Oil
d D B Cr Cor RPM RPM
mm mm mm KN KN r/min r/min
51100 10 24 ㅡ 10 13.3 7000 9500
51200 10 26 ㅡ 12.7 16.2 6000 8000
51101 12 26 ㅡ 10.3 14.5 7000 9500
51201 12 28 ㅡ 13.2 18.1 6000 8000
51102 15 28 ㅡ 10.5 13.3 6300 8500
51202 15 32 ㅡ 14.2 15.8 5300 7000
51202/YB2 15 32 ㅡ 14.2 15.8 5300 7000
51103 17 30 ㅡ 10.8 13.4 6300 8500
51203 17 35 ㅡ 17.2 26.1 5300 7000
51104 20 35 ㅡ 13.4 18.6 5600 7500
51204 20 40 ㅡ 22.3 35.6 4500 6000
51105 25 42 ㅡ 17.4 27.6 4800 6300
51205 25 47 ㅡ 27.8 47.5 4000 5300
51305 25 52 ㅡ 35.7 52.3 3400 4500
51405 25 60 ㅡ 55.5 85.5 2600 3600
51106 30 47 ㅡ 18.1 31.8 4500 6000
51206 30 52 ㅡ 28.1 45.1 3600 4800
51306 30 60 ㅡ 42.8 62.2 2800 3800
51406 30 70 ㅡ 72.7 119 2200 3200
51107 35 52 ㅡ 21.2 38.2 4300 5600
51207 35 62 ㅡ 39.2 63.7 3200 4300
51307 35 68 ㅡ 55.4 83.6 2400 3400
51407 35 80 ㅡ 87 148 1800 2600
51408 40 90 ㅡ 112 194 1700 2400
51108 40 60 ㅡ 26.9 47.5 3800 5000
51208 40 68 ㅡ 47 93.1 2800 3800
51308 40 78 ㅡ 69.2 106 2000 3000
51409 45 100 ㅡ 141 228 1600 2200
51109M 45 65 ㅡ 31.6 108 3400 4500
51209 45 73 ㅡ 47.8 81 2600 3600
51309 45 85 ㅡ 75.8 133 1900 2800
51109 45 65 ㅡ 27 54.2 3400 4500
51110 50 70 ㅡ 27.1 59.9 3400 4500
51210 50 78 ㅡ 48.5 101 2400 3400
51310 50 95 ㅡ 96.6 164 1800 2600
51410 50 110 ㅡ 160 295 1500 2000
51111 55 78 ㅡ 34.4 74.1 3000 4000
51211 55 90 ㅡ 67.6 127 2000 3000
51311 55 105 ㅡ 114.5 198 1600 2200
51411 55 120 ㅡ 183 342 1300 1800
51112 60 85 ㅡ 40.3 87 2600 3600
51212 60 95 ㅡ 73.6 141 1900 2800
51312 60 110 ㅡ 118 208 1600 2200
51412 60 130 ㅡ 201 380 1200 1700
51113 65 90 ㅡ 41.7 103 2400 3400
51213 65 100 ㅡ 74.9 151 1800 2600
51313 65 115 ㅡ 116 228 1600 2200
51413 65 140 ㅡ 217 428 1000 1500
51114 70 95 ㅡ 42 119 2400 3400
51214 70 105 ㅡ 73.6 161 1800 2600
51314 70 125 ㅡ 148 285 1400 1900
51414 70 150 ㅡ 257 475 950 1400
51115 75 100 ㅡ 44 130 2200 3200
51215 75 110 ㅡ 74.9 173 1700 2400
51315 75 135 ㅡ 163 342 1200 1700
51415 75 160 ㅡ 269 532 900 1300
51116 80 105 ㅡ 48.8 133 2000 3000
51216 80 115 ㅡ 83.8 193 1700 2400
51316 80 140 ㅡ 178 342 1200 1700
51416 80 170 ㅡ 292 589 850 1200
51417 85 180 ㅡ 318 646 850 1200
51117 85 110 ㅡ 49.2 143 2000 3000
51217 85 125 ㅡ 103 238 1600 2200
51317 85 150 ㅡ 209 404 1100 1600
51218 90 135 ㅡ 125 285 1500 2000
51318M 90 155 ㅡ 221 408 1000 1500
51418 90 190 ㅡ 327 713 800 1100
51118 90 120 ㅡ 65.1 181 1800 2600
51120 100 135 ㅡ 85.1 257 1700 2400
51220M 100 150 ㅡ 149 347 1300 1800
51320M 100 170 ㅡ 263 513 950 1400
51420 100 210 ㅡ 399 917 700 950
51122 110 145 ㅡ 87.2 276 1600 2200
51222 110 160 ㅡ 139 393 1200 1700
51322 110 190 ㅡ 280 684 850 1200
51422 110 230 ㅡ 415 1150 630 850
51422/HE 110 230 ㅡ 491 1397 630 850
51124 120 155 ㅡ 87.1 295 1600 2200
51224 120 170 ㅡ 136 399 1200 1700
51324 120 210 ㅡ 330 869 800 1100
51126 130 170 ㅡ 109 371 1400 1900
51226 130 190 ㅡ 186 535 950 1400
51326 130 225 ㅡ 358 1007 750 1000
51426 130 270 ㅡ 490 1520 560 750
LY-5014 130 155 ㅡ 41.5 158 1500 2000
51128 140 180 ㅡ 111 380 1300 1800
51228 140 200 ㅡ 191 542 950 1400
51328 140 240 ㅡ 396 1159 700 950
51428 140 280 ㅡ 553 1750 500 700
51130 150 190 ㅡ 112 380 1200 1700
51230 150 215 ㅡ 244 698 900 1300
51330 150 250 ㅡ 407 1226 670 900
51132 160 200 ㅡ 112 404 1200 1700
51232 160 225 ㅡ 240 741 850 1200
51332 160 270 ㅡ 463 1425 630 850
51134 170 215 ㅡ 137 475 1100 1600
51234 170 240 ㅡ 280 884 800 1100
51334 170 280 ㅡ 445 1520 600 800
51136 180 225 ㅡ 135 504 1000 1500
51236 180 250 ㅡ 294 950 800 1100
51336 180 300 ㅡ 494 1738 560 750
51338M 190 320 ㅡ 544 1480 520 700
LY-Z093 200 340 ㅡ 624 2400 500 700
51144 220 270 ㅡ 179 740 950 1400
8949M 238 340 ㅡ 365 1140 580 750
51152 260 320 ㅡ 218 994 800 1100
51252 260 360 ㅡ 450 1900 560 750
51256 280 380 ㅡ 493 1950 560 750
51160 300 380 ㅡ 322 1634 630 850
51260 300 420 ㅡ 575 2613 480 630
51264 320 440 ㅡ 543 2565 450 600
51164 320 400 ㅡ 352 1756 600 800
51168 340 420 ㅡ 358 1768 600 800
51268 340 460 ㅡ 575 2755 450 600
51368 340 540 ㅡ 1020 5100 200 250
51172X2 360 440 ㅡ 371 1805 560 750
51172 360 440 ㅡ 371 1890 560 750
51272 360 500 ㅡ 704 3610 400 530
708773y 365 475 ㅡ ㅡ ㅡ ㅡ ㅡ
8974H 370 529 ㅡ ㅡ ㅡ ㅡ ㅡ
51180 400 480 ㅡ 403 2014 530 700
51280 400 540 ㅡ 730 3800 250 380
59280 400 540 ㅡ 668 3250 330 470
50980/YB2 400 440 ㅡ 140 700 1300 1600
51184 420 500 ㅡ 410 2090 530 700
51784 420 550 ㅡ 463 2574 500 650
51188 440 540 ㅡ 552 2730 450 600
59188/YB2 440 540 ㅡ 360 2112 360 500
51288 440 600 ㅡ 904 4150 320 470
51791 455 650 ㅡ 776 4851 350 500
51192 460 560 ㅡ 527 2850 450 600
51292 460 620 ㅡ 688 4504 200 300
51196X1 480 600 ㅡ 585 3165 448 640
51196 480 580 ㅡ 530 3100 430 560
51396 480 730 ㅡ 1065 6886 230 330
510/500 500 540 ㅡ 101 835 1100 1500
511/500 500 600 ㅡ 595 3250 430 560
512/500 500 670 ㅡ 864 5443 250 300
593/500 500 750 ㅡ 950 6320 180 220
511/530 530 640 ㅡ 618 3311 400 530
590/560 560 610 ㅡ 128 960 560 800
591/600 600 710 ㅡ 630 4275 380 500
511/600 600 710 ㅡ 689 4445 360 470
511/630 630 750 ㅡ 744 4680 350 480
512/630 630 850 ㅡ 1400 10000 100 160
517/630 630 810 ㅡ 894 5058 302 432
517/635/YB2 635 787.4 ㅡ 730 4690 341 488
511/670X2 670 800 ㅡ 852 4900 318 454
510/670 670 730 ㅡ 284 2160 380 530
511/670 670 800 ㅡ 683 5778 160 240
9089/708 708 950 ㅡ 775 970 150 220
572/710 710 950 ㅡ 787 980 150 220
592/710 710 950 ㅡ 1025 1296 150 220
591/750V 750 900 ㅡ 810 6210 160 240
591/750 750 900 ㅡ 741 4900 303 433
517/780 780 930 ㅡ 800 6069 140 200
512/800 800 1060 ㅡ 1810 12570 130 180
517/800 800 920 ㅡ 825 6120 140 200
511/850 850 1000 ㅡ 885 6770 220 314
LY-5004 880 1020 ㅡ 840 6620 284 406
517/980 980 1120 ㅡ 940 7880 200 284
9089/1035 1035 1300 ㅡ 823 1170 160 260
591/1060 1060 1250 ㅡ 940 1240 140 200
517/1095/HG2 1095 1205 ㅡ 377 2708 353 504
510/1080 1180 1280 ㅡ 738 7680 150 220
517/1720V 1720 1880 ㅡ 988 12243 180 258
517/2860V 2860 3140 ㅡ 2434 42494 28 40
517/3000V 3000 3250 ㅡ 1612 29858 53 76
Designation Principal dimensions
d D
mm mm
51100 10 24
51200 10 26
51101 12 26
51201 12 28
51102 15 28
51202 15 32
51202/YB2 15 32
51103 17 30
51203 17 35
51104 20 35
51204 20 40
51105 25 42
51205 25 47
51305 25 52
51405 25 60
51106 30 47
51206 30 52
51306 30 60
51406 30 70
51107 35 52
51207 35 62
51307 35 68
51407 35 80
51408 40 90
51108 40 60
51208 40 68
51308 40 78
51409 45 100
51109M 45 65
51209 45 73
51309 45 85
51109 45 65
51110 50 70
51210 50 78
51310 50 95
51410 50 110
51111 55 78
51211 55 90
51311 55 105
51411 55 120
51112 60 85
51212 60 95
51312 60 110
51412 60 130
51113 65 90
51213 65 100
51313 65 115
51413 65 140
51114 70 95
51214 70 105
51314 70 125
51414 70 150
51115 75 100
51215 75 110
51315 75 135
51415 75 160
51116 80 105
51216 80 115
51316 80 140
51416 80 170
51417 85 180
51117 85 110
51217 85 125
51317 85 150
51218 90 135
51318M 90 155
51418 90 190
51118 90 120
51120 100 135
51220M 100 150
51320M 100 170
51420 100 210
51122 110 145
51222 110 160
51322 110 190
51422 110 230
51422/HE 110 230
51124 120 155
51224 120 170
51324 120 210
51126 130 170
51226 130 190
51326 130 225
51426 130 270
LY-5014 130 155
51128 140 180
51228 140 200
51328 140 240
51428 140 280
51130 150 190
51230 150 215
51330 150 250
51132 160 200
51232 160 225
51332 160 270
51134 170 215
51234 170 240
51334 170 280
51136 180 225
51236 180 250
51336 180 300
51338M 190 320
LY-Z093 200 340
51144 220 270
8949M 238 340
51152 260 320
51252 260 360
51256 280 380
51160 300 380
51260 300 420
51264 320 440
51164 320 400
51168 340 420
51268 340 460
51368 340 540
51172X2 360 440
51172 360 440
51272 360 500
708773y 365 475
8974H 370 529
51180 400 480
51280 400 540
59280 400 540
50980/YB2 400 440
51184 420 500
51784 420 550
51188 440 540
59188/YB2 440 540
51288 440 600
51791 455 650
51192 460 560
51292 460 620
51196X1 480 600
51196 480 580
51396 480 730
510/500 500 540
511/500 500 600
512/500 500 670
593/500 500 750
511/530 530 640
590/560 560 610
591/600 600 710
511/600 600 710
511/630 630 750
512/630 630 850
517/630 630 810
517/635/YB2 635 787.4
511/670X2 670 800
510/670 670 730
511/670 670 800
9089/708 708 950
572/710 710 950
592/710 710 950
591/750V 750 900
591/750 750 900
517/780 780 930
512/800 800 1060
517/800 800 920
511/850 850 1000
LY-5004 880 1020
517/980 980 1120
9089/1035 1035 1300
591/1060 1060 1250
517/1095/HG2 1095 1205
510/1080 1180 1280
517/1720V 1720 1880
517/2860V 2860 3140
517/3000V 3000 3250

Thrust Ball Bearings

Double direction thrust ball bearings with flat back face

These bearings are designed to handle axial loads in both directions but cannot carry radial loads. Double-direction thrust ball bearings feature a flat housing washer and a self-aligning seat washer. As with single-direction versions, the housing washer typically does not allow for angular misalignment. A 0.5-1 mm gap between the housing washer and mounting surface can help accommodate slight angular errors.

Important:
  • Self-aligning seat washers must be custom-ordered for specific applications.
Typical Applications:
  • Suitable for machine tool spindles, gear assemblies, and high-precision machinery requiring stable axial support.
Designation Principal dimensions Basic load ratings Limiting speed
Dynamic Static Grease Oil
d D B Cr Cor RPM RPM
mm mm mm KN KN r/min r/min
527/1181 ㅡ 1280 ㅡ 1192 7680 150 220
527/1520 ㅡ 1720 ㅡ 2616 20520 51 73
9038980 ㅡ 440 ㅡ ㅡ ㅡ ㅡ ㅡ
527/940 ㅡ 1030 ㅡ 796 4272 280 400
527/950.8 ㅡ 1030 ㅡ 796 4272 260 370
527/950.8YB2 ㅡ 1030 ㅡ 796 4272 280 400
2327/1049/YA ㅡ 1250 ㅡ 1223 9989 99 142
Designation Principal dimensions
d D
mm mm
527/1181 ㅡ 1280
527/1520 ㅡ 1720
9038980 ㅡ 440
527/940 ㅡ 1030
527/950.8 ㅡ 1030
527/950.8YB2 ㅡ 1030
2327/1049/YA ㅡ 1250

Thrust Ball Bearings

Angular contact trust ball bearings

Angular contact thrust ball bearings are designed primarily to carry axial loads, with the added ability to support some radial load. Compared to standard thrust ball bearings of similar size, angular contact variants offer a higher limiting speed and can be used for axial location in one direction. They feature contact angles of 45° and 60°, with smaller angles allowing for higher radial load capacity.

Benefits:
  • Supports both axial and radial loads.
  • Higher speed capability than traditional thrust ball bearings.
  • Provides enhanced radial load capacity, overcoming the limitations of flat-back thrust ball bearings.
Designation Principal dimensions Basic load ratings Limiting speed
Dynamic Static Grease Oil
d D B Cr Cor RPM RPM
mm mm mm KN KN r/min r/min
569164 320 400 ㅡ 260 1115 830 1100
569164/YB2 330 410 ㅡ 111 607 600 900
569176/YB2 380 470 ㅡ 177 602 500 730
569184 420 500 ㅡ 260 1440 830 1100
567284 420 580 ㅡ 330 2010 700 980
569188 440 540 ㅡ 380 1980 660 950
5691/500 500 600 ㅡ 322 1956 660 950
5617/520 520 620 ㅡ 440 2430 660 950
5692/530 530 710 ㅡ 695 4320 350 500
5692/530/YB2 530 710 ㅡ 780 4250 350 500
5617/560 560 740 ㅡ 805 3432 400 570
5617/562 562 632 ㅡ 143 500 300 440
5691/600 600 710 ㅡ 380 2484 510 720
5617/610 610 790 ㅡ 839 3648 380 540
5617/620 620 780 ㅡ 776 3588 340 490
1688/620 620 700 ㅡ 311 1314 260 380
5617/650 650 880 ㅡ 1105 7692 260 370
5692/670 670 900 ㅡ 1260 6084 250 360
5691/750 750 900 ㅡ 587 4620 340 480
5611/800 800 950 ㅡ 850 6710 200 240
5692/800 800 1060 ㅡ 1145 8868 180 250
5617/810 810 1030 ㅡ 780 4080 280 400
5691/950 950 1250 ㅡ 1500 9168 120 170
5691/1000 1000 1180 ㅡ 1076 6516 250 360
5691/1120 1120 1320 ㅡ 1018 10272 180 260
5617/1270 1270 1430 ㅡ 1100 10859 170 250
5617/1600 1600 1760 ㅡ 682 8052 210 300
5617/1860 1860 2100 ㅡ 1272 19370 93 130
5617/2100 2100 2280 ㅡ 1200 19300 78 111
5610/2500 2500 2700 ㅡ 1584 26640 57 81
5617/2530V/HG2 2530 2650 ㅡ 954 7500 50 80
5617/3000/YA 3000 3270 ㅡ 1464 24240 52 75
Designation Principal dimensions
d D
mm mm
569164 320 400
569164/YB2 330 410
569176/YB2 380 470
569184 420 500
567284 420 580
569188 440 540
5691/500 500 600
5617/520 520 620
5692/530 530 710
5692/530/YB2 530 710
5617/560 560 740
5617/562 562 632
5691/600 600 710
5617/610 610 790
5617/620 620 780
1688/620 620 700
5617/650 650 880
5692/670 670 900
5691/750 750 900
5611/800 800 950
5692/800 800 1060
5617/810 810 1030
5691/950 950 1250
5691/1000 1000 1180
5691/1120 1120 1320
5617/1270 1270 1430
5617/1600 1600 1760
5617/1860 1860 2100
5617/2100 2100 2280
5610/2500 2500 2700
5617/2530V/HG2 2530 2650
5617/3000/YA 3000 3270
